MasterPi AI Vision Chassis with Mecanum Wheels and Robot Arm

Stable power supply assured with an autonomous power switch.
Over-current safeguard for the 6-channel PWM servo ports.
Embedded MCU to lighten the load on the Raspberry Pi and optimize resource consumption.
Equipped with various features like RGB light, buzzer, and LED light.
Expandability facilitated through three IIC ports.
Numerous GPIO pins available for development purposes.
Compatibility with Hiwonder sensors ensured with 4PIN anti-reverse ports.

₹26,999.00 ~~₹29,999.00~~

Description
Reviews

Powered by Raspberry Pi 4B and equipped with mecanum wheel chassis car, 5DOF robotic arm and HD camera, MasterPi is able to carry out color sorting, target tracking, line following, intelligent transport, etc by OpenCV.

Combining with RGB glowy ultrasonic sensor, it can control light colors and perform obstacle avoidance. In addition, various sensors can be installed on MasterPi for more perception functions. With abundant tutorials and open source Python codes, MasterPi is a perfect helper for you to learn robot technology and robot vision to be a real AI player!

Smart Games Make Programming Learning More Fun

Color Recognition

Color Sorting

Target Tracking

Line Following

Obstacle Avoidance

Remote Control

Omni-directional Movement, First Person View

360° Omni-directional Movement

With omni-directional mecanum wheels, MasterPi can realize 360°movement. Different movement modes (move forward, horizontally, diagonally and rotate ) and excellent performance enable it challenge various complicated routes easily.

Object Transport, First Person View

Loaded with a 5DOF robotic arm, MasterPi can pick and transport the target object with ease. Combined with HD camera ending in robot arm, it can provide first person view.

AI Vision Recognition, Target Tracking

MasterPi takes OpenCV as image processing library and utilizes FPV to recognize and locate the target block so as to realize color sorting, target tracking, line following, and other AI games.

Color Sorting

With abundant tutorials and open source Python codes, robotic arm can carry out color recognition, picking and sorting.

Target Tracking

Through vision positioning of the target object and inverse kinematics algorithm of the robotic arm, the target object can be better targeted and tracked.

Line Following

Through extracting ROI area with OpenCV, eliminating noise, image binaryzation and etc, to realize line following

First Person View, HD Transmitted Image

MasterPi supports WLAN and WIFI direct connection modes. Connecting WiFi, the first person view will be returned to app operation interface, which gets remote control more exciting and real!

Real-time Remote Control

Use App to control Masterpi to move, pick and transport at your fingertips

Quick Experience AI Games

Switch robot modes easily and quickly to experience AI games.

Supports Python

6 Hardware Features

15KG Strong Torque

The base of robotic arm uses full metal and 15KG strong torque servo equipped with metal servo horn for stronger power feedback.

Metal Gear Micro Servo

The end of robotic arm uses metal gear micro servo equipped with metal servo horn for higher accuracy and longer service life！

Hard Aluminium Alloy

It protects the core control board from shattering and shocking and can bear bigger load!

120° HD Camera

Loaded with 120 °camera, visual angle and tilt angle can reach 180°. Combined with mecanum chassis car, the vision range is 360°.

Glowy Ultrasonic Sensor

Lower CPU consumption for better performance. Distance to obstacles and light colors are adjustable in App.

Powerful Control System

Compared with the previous generation of Raspberry Pi, RaspberryPi 4B makes breakthrough in processor speed, multimedia performance, memory and connection. The combination of RaspberryPi 4B and RaspberryPi expansion board significantly enhances MasterPi’s AI performance!
